Stainless steel bright annealing furnace
Maximum temperature: 1350°C
Ultimate vacuum: 10pa, 6.7×10-3pa
Temperature uniformity: ±5°C
Temperature control accuracy: ±1°C
Pressure rising rate: --
Process application: Bright annealing of tool steel, die steel, ultra-high strength steel, high temperature alloy steel, stainless steel, magnetic materials, titanium alloys, non-ferrous metals, etc.Chat OnlineLeave Message
Introduction
Features:
1. The rotary vane pump, diffusion pump and Roots pump set achieve high vacuum to ensure the processing quality of the workpiece.
2. The heating elements are evenly arranged to ensure the uniformity of the furnace temperature.
3. Metal molybdenum heating, stainless steel insulation, and high furnace cleanliness
4. The touch screen interface is friendly and practical. It can display and monitor the operating status of the equipment, call, edit and store the sintering process, and has dynamic display, historical data can be recorded and exported.
5. With safety interlock, fault diagnosis and abnormal alarm functions
Application
Bright annealing of tool steel, die steel, ultra-high strength steel, high temperature alloy steel, stainless steel, magnetic materials, titanium alloys, non-ferrous metals, etc.
Treatment material
Specifications - Technical Data
| Stainless steel bright annealing furnace | |||||
| Model | KJ-JS223 (optional) | KJ-JS334 (optional) | KJ-JS446 | KJ-JS557 (optional) | KJ-JS669 (optional) |
| Heating area (mm) | 200×200×300 | 300×300×400 | 400×400×600 | 500×500×700 | 600×600×900 |
| Heating power (Kw) | 25 | 50 | 75 | 95 | 150 |
| Maximum temperature (℃) | 1350 | 1350 | 1350 | 1350 | 1350 |
| Ultimate vacuum (Pa) | 10pa, 6.7×10-3pa | ||||
| Heating element | Metal molybdenum belt | ||||
| structure | Single indoor thermal horizontal structure | ||||
| Heating rate | 0-20℃/min | ||||
| More specifications can be customized according to requirements | |||||
The above parameters can be adjusted according to process requirements and are not used as acceptance basis. The specific technical plan and agreement shall prevail.
Customized service
KJ Technology provides you with comprehensive customized services with excellent quality to meet your different needs.
- Furnace structure customization
We support customization of door structure, temperature zone control, electrical control, etc.
- Furnace chamber customization
Different furnace volumes and sizes can be customized according to the customer's processing volume.
- Atmosphere vacuum conditions
We can provide customers with different atmospheres and meet vacuum conditions.
- Heating temperature customization
We can provide customization of heating ranges in different temperature ranges from 0℃ to 2000℃.
